Place of Origin:
Henan, China
Brand Name:
Lanphan
Certification:
CE ISO
Model Number:
HFD-6
Vacuum Freeze Dryer Machine System for Candy
Freeze Dryer Features
Integrated structure, small size, easy to use, no leakage
Materials in contact with the product meet food grade requirements
The cold trap is made of stainless steel, which is anti-corrosion and easy to clean
With sample pre-freezing function
The cold trap captures ice evenly; strong ice capture ability
International famous brand compressor, which are high efficiency, energy saving, long service life, low noise.
Well-known brand vacuum pump, which are high pumping speed and higher ultimate vacuum.
Intelligently record and export data
what is the freeze dryer
Home freeze dryer is a small vacuum freeze dryer.
It is suitable for home use and small amount of freeze-dried use.
It is widely used in freeze-drying of fruits, vegetables, meat, Chinese herbal medicines, health care products, etc.
It is a trend that freeze dryers are developed from specific uses to households.
Freeze-dried food and medicinal materials are easy to be stored for a long time, which can retain the taste, nutritional content and shape of the original material to the greatest extent.
Home Freeze Dryer Application
Home freeze dryers are widely used in the food industry. It can be used for freeze drying of fruits, vegetables, candy, meat. The freeze dryer is easy to operate. Compared to dehydrated foods, freeze-dried foods greatly retain the nutrients of the product. It can also be used in the pet food industry.
Home Freeze Dryer Parameter
Product Model | KWD-HFD-1 | KWD-HFD-4 | KWD-HFD-6 |
Freeze-dried Area | 0.1㎡ | 0.4㎡ | 0.6㎡ |
Cold Trap Coil Temperature | <-40℃ (no-load) | ||
Ultimate Vacuum | 15pa (no-load) | ||
Power Supply | 220V 50HZ | ||
Power | 750W | 1100W | 2300W |
Handling Capacity | 1-2KG / batch | 4-6KG / batch | 6-8kg / batch |
Layer Spacing | 45mm | 45mm | 50mm |
Weight | 50KG | 80KG | 120KG |
Material Tray Size | 140mm x 278mm three layers | 200mm x 450mm four layers | 300mm x 400mm four layers |
Dimension | 400mm x 550mm x700mm | 510mm x 700mm 850mm | 700mm x 800mm x 1300mm |
Freeze Dryer Details
